Irfan Pipes and Tubes, based in Istanbul, Turkey, stands out as a top manufacturer and supplier of high-quality Titanium Boiler Tubing, specifically crafted for demanding applications in power generation and industrial boilers. These tubes are made from premium titanium or titanium alloys, providing outstanding corrosion resistance, lightweight strength, and impressive durability over time. Designed to perform reliably in high-temperature, high-pressure, and chemically aggressive settings, Titanium Boiler Tubing features precise dimensions and smooth finishes, all while meeting international standards. Irfan Pipes and Tubes delivers tailored tubing solutions that fulfill critical industrial needs, making them a go-to choice for boiler and heat exchanger systems around the globe.
Titanium Boiler Tubing is generally crafted from commercially pure titanium (Grades 1–4) or titanium alloys (Grades 5–7), showcasing remarkable tensile and yield strength. This tubing is known for its exceptional corrosion resistance against both oxidizing and reducing environments, including seawater and various boiler chemicals. It’s lightweight yet incredibly strong, boasting high toughness, fatigue resistance, and thermal stability even under high-pressure and high-temperature conditions. Additionally, the tubing offers excellent weldability, ductility, and precise dimensional accuracy, making it ideal for boiler and heat exchanger systems where long-lasting performance, corrosion resistance, and mechanical reliability are crucial.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
Tolerance | Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or beveled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing | A. Sanded |
| B. Gloss #400,Mirror #600 – #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Boiler Tubing from Irfan Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Irfan Pipes and Tubes, a leading supplier of Titanium Boiler Tubing in Istanbul, Turkey, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Irfan Pipes and Tubes, we provide custom sizes of Titanium Boiler Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@irfanpipes.com.
Titanium Boiler Tubing finds extensive use in the power generation, chemical, and industrial sectors that demand high corrosion resistance and mechanical strength. In boiler and heat exchanger systems, it’s utilized for transporting steam, water, and condensates under high pressure and temperature. The chemical industry relies on titanium tubing for handling corrosive fluids in boiler feedwater and heat recovery systems. In marine and offshore applications, its lightweight and durable properties make it a preferred choice for various demanding environments.
