Irfan Pipes and Tubes, based in Istanbul, Turkey, stands out as a top manufacturer and supplier of premium stainless steel piping products. One of their key offerings is the Stainless Steel 348 Pipes, which are renowned for their exceptional performance in high-temperature and corrosive settings. With a strong commitment to quality, precision, and customer satisfaction, Irfan Pipes and Tubes ensures that their products meet international standards and certifications. They cater to a diverse array of industries, including petrochemical, power, and aerospace, and have built a solid reputation for reliability, competitive pricing, and timely delivery both domestically and internationally.
Stainless Steel 348 Pipes are a type of stabilized austenitic stainless steel, containing 17-20% Chromium, 9-13% Nickel, and Niobium (Columbium) to enhance their resistance to intergranular corrosion. The inclusion of Niobium, which is present at 8 to 10 times the carbon content, helps to prevent carbide precipitation during welding and high-temperature applications. These pipes boast impressive mechanical properties, featuring a minimum tensile strength of 515 MPa, yield strength of 205 MPa, and an elongation of 35–40%. Stainless Steel 348 is particularly well-suited for high-temperature uses due to its excellent creep resistance and thermal stability.
| Sizes: | 1/8″ to 24″ |
| ASTM A312 Steel grades: | TP304/304L/304H |
| ASTM A312 Schedules: | STD, XS, XXS, SCH5S, SCH10/10S, SCH20, SCH30, SCH40/40S, SCH60, SCH80/80S, SCH100, SCH120, SCH140, SCH160 |
| Standards: | ASTM A312, ASME SA312 |
| Lengths: | SRL and DRL 5meters up to 11meters available from Stock or Production. |
| Ends: | Plain/Bevelled |
| Element | Content (%) |
|---|---|
| Iron, Fe | 66 |
| Chromium, Cr | 19 |
| Nickel, Ni | 11 |
| Manganese, Mn | 2.0 |
| Silicon, Si | 1.0 |
| Nb + Ta | 0.8 |
| Cobalt, Co | 0.2 |
| Tantalum, Ta | 0.1 |
| Carbon, C | 0.080 |
| Phosphorous, P | 0.045 |
| Sulfur, S | 0.030 |
| Properties | Metric | Imperial |
|---|---|---|
| Tensile strength | 655 MPa | 95000 psi |
| Yield strength (@ strain 0.200%) | 275 MPa | 39900 psi |
| Izod impact | 120 – 160 J | 88.5 – 118 ft-lb |
| Charpy impact | 160 J | 118 ft-lb |
| Shear modulus (typical for steel) | 77.0 GPa | 11200 ksi |
| Elastic modulus | 190-210 GPa | 27557-30458 ksi |
| Poisson’s ratio | 0.27-0.30 | 0.27-0.30 |
| Elongation at break (in 50 mm) | 45% | 45% |
| Hardness, Brinell (converted from Rockwell B hardness) | 147 | 147 |
| Hardness, Knoop (converted from Rockwell B hardness) | 164 | 164 |
| Hardness, Rockwell B | 85 | 85 |
| Hardness, Vickers (converted from Rockwell B hardness) | 169 | 169 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 348 Pipes from Irfan Pipes and Tubes offers a unique and durable look, ideal for a variety of industrial applications. Their pipes are highly resistant to corrosion and oxidation, making them suitable for harsh environments. Irfan’s commitment to standardized manufacturing assures consistent design and performance standards. In addition, their extensive inventory ensures on-time delivery, reducing downtime. The company’s focus on customer satisfaction means tailored solutions for specific needs. With competitive pricing and strong after-sales support, Irfan stands out as a trusted partner in your piping needs. Count on their expertise to improve your work efficiency and reliability.
Irfan Pipes and Tubes, one of the largest suppliers of Stainless Steel 348 Pipes in Istanbul, Turkey, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| NPS | OD | SCH 5S | SCH 10S | SCH 40S | SCH 80S |
| 1/4 | 13.72 | – | 1.65 | 2.24 | 3.02 |
| 3/8 | 17.15 | – | 1.65 | 2.31 | 3.2 |
| 1/2 | 21.34 | 1.65 | 2.11 | 2.77 | 3.73 |
| 3/4 | 26.67 | 1.65 | 2.11 | 2.87 | 3.91 |
| 1 | 33.4 | 1.65 | 2.77 | 3.38 | 4.55 |
| 1.25 | 42.16 | 1.65 | 2.77 | 3.56 | 4.85 |
| 1.5 | 48.26 | 1.65 | 2.77 | 3.68 | 5.08 |
| 2 | 60.33 | 1.65 | 2.77 | 3.91 | 5.54 |
| 2.5 | 73.03 | 2.11 | 3.05 | 5.16 | 7.01 |
| 3 | 88.9 | 2.11 | 3.05 | 5.49 | 7.62 |
| 3.5 | 101.6 | 2.11 | 3.05 | 5.74 | 8.08 |
| 4 | 114.3 | 2.11 | 3.05 | 6.02 | 8.56 |
| 5 | 141.3 | 2.77 | 3.4 | 6.55 | 9.53 |
| 6 | 168.28 | 2.77 | 3.4 | 7.11 | 10.97 |
| 8 | 219.08 | 2.77 | 3.76 | 8.18 | 12.7 |
| 10 | 273.05 | 3.4 | 4.19 | 9.27 | 12.7 |
| 12 | 323.85 | 3.96 | 4.57 | 9.53 | 12.7 |
| 14 | 355.6 | 3.96 | 4.78 | 9.53 | 12.7 |
| 16 | 406.4 | 4.19 | 4.78 | 9.53 | 12.7 |
| 18 | 457.2 | 4.19 | 4.78 | 9.53 | 12.7 |
| 20 | 508 | 4.78 | 5.54 | 9.53 | 12.7 |
| 22 | 558.8 | 4.78 | 5.54 | – | – |
| 24 | 609.6 | 5.54 | 6.35 | 9.53 | 12.7 |
| 26 | 660.4 | – | – | – | – |
| 28 | 711.2 | – | – | – | – |
| 30 | 762 | 6.35 | 7.92 | – | – |
Yes, we offer custom sizes for Stainless Steel 348 Pipes to meet your specific requirements. Our team at Irfan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@irfanpipes.com.
Stainless Steel 348 Pipes find extensive use in high-temperature and high-stress environments where outstanding mechanical strength and corrosion resistance are essential. They are commonly utilized in heat exchangers, boiler tubes, exhaust manifolds, and chemical processing equipment. Their effectiveness shines in nuclear and aerospace applications, where resistance to thermal fatigue and intergranular corrosion is vital. Furthermore, Stainless Steel 348 is often employed in the pharmaceutical, food processing, and refinery sectors for equipment that must withstand demanding conditions.
