Stainless Steel 317 Pipes

Home > Stainless Steel > Stainless Steel 317 Pipes

Stainless Steel 317 Pipes Manufacturer, Supplier and Exporter in Istanbul, Turkey

Irfan Pipes and Tubes, located in Istanbul, Turkey, has built a solid reputation as a manufacturer and supplier of top-notch stainless steel piping solutions for a variety of industrial sectors. One of their standout products is the Stainless Steel 317 Pipes, crafted from austenitic stainless steel that offers exceptional corrosion resistance in harsh chemical environments. Renowned for their durability, precision, and adherence to global standards, the company caters to industries like chemical processing, marine, pulp and paper, and food production. With a strong focus on customer satisfaction, Irfan Pipes and Tubes ensures reliable products, backed by technical know-how, competitive pricing, and swift global delivery.

317 Stainless Steel Pipes Exporter in Turkey, SS UNS S31700 Pipes Exporter in Bursa, 317 Stainless Steel Pipe Manufacturer in Ankara, SUS 317 Pipes Price List in İzmir, ASTM A312 Stainless Steel 317 Pipe Supplier in Bodrum, Stainless Steel 1.4449 Pipes in Antalya

Stainless Steel 317 Pipes are made from high-alloy austenitic stainless steel, featuring 18–20% Chromium, 11–15% Nickel, and 3–4% Molybdenum, with a carbon content of up to 0.08%. This unique composition enhances their resistance to pitting, crevice corrosion, and chemical attacks in acidic and chloride-rich settings. The alloy boasts a tensile strength of ≥515 MPa, yield strength of ≥205 MPa, and an elongation of 35–40%. Compared to 316, SS 317 provides superior creep resistance, stress-to-rupture, and tensile strength at elevated temperatures, making it perfect for demanding operating conditions.

Stainless Steel 317 Pipes Specification

Specifications	ASTM A312, A358 / ASME SA312, SA358
Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24″ NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Thickness Range	0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type	Seamless / ERW / Welded / Fabricated / CDW
Form	Round Pipes, Square Pipes, Rectangular Pipes
Length	Single Random, Double Random & Required Length
End	Plain End, Beveled End, Treaded
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
EN 10216-5	EN 10216 317/317L Seamless Steel Pipe, EN 10216-5 1.4449 / 1.4438 Seamless Steel Pipes for pressure purposes
EN 10217-7	EN 10217 317/317L Welded Steel Pipe, Steel EN 10217-7 1.4449 / 1.4438 Welded Pipes for pressure purposes

Stainless Steel 317 Pipes Chemical Composition

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	N
317	0.08 max	2 max	1 max	0.040 max	0.03 max	18 – 20	3 – 4	11 – 14	–

SS 317 Pipes Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.9 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

SS 317 Schedule 40 Pipe Price List in Istanbul, Stainless Steel S31700 Pipes Supplier in Bursa, SS 317 Pipes Supplier in Turkey, ASTM A312 Stainless Steel 317 Pipe Exporter in Ankara, AISI 317 Pipes Exporter in Bodrum, 1 inch SS 317 Pipe Price in Antalya, SS 317 Pipe Weight Chart, SS 317 Schedule 20 Pipe Thickness, 317 Austenitic Stainless Steel Pipe Supplier in İzmir

Why Choose Stainless Steel 317 Pipes from Irfan Pipes and Tubes?

Choosing Stainless Steel 317 Pipes from Irfan Pipes and Tubes offers excellent corrosion resistance, making it ideal for harsh environments. Our pipes are manufactured to the highest standards, making them durable and reliable. We provide customized solutions to meet the specific needs of the business. With competitive pricing and exceptional customer service, we guarantee a smooth shopping experience. Trust Irfan for your piping needs and enjoy unparalleled performance and longevity.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 317 Pipes Supplier in Istanbul, Turkey

Irfan Pipes and Tubes, one of the largest suppliers of Stainless Steel 317 Pipes in Istanbul, Turkey, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

Stainless Steel 317 Pipes Sizes in MM

Designation of Diameter		O/D	Nominal Wall Thickness
Designation of Diameter		DIA	SCH.5S		SCH.5		SCH 10S		SCH.10		SCH.20S		SCH.30		SCH.40S		SCH.40		SCH 60
(A)	(B)	Meter MM	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr	Wall Thk	Weight Kg/Mtr
6	1/8	10.3	1	0.23			1.2	0.27			1.5	0.33			1.73	0.37
8	1/4	13.7	1.2	0.37			1.65	0.49			2	0.58			2.24	0.64
10	3/8	17.2	1.2	0.47			1.65	0.63			2	0.74			2.31	0.87
15	1/2	21.3	1.65	0.01	1.65	0.81	2.11	1.02	2.11	1.02	2.5	1.15			2.77	1.29
20	3/4	26.7	1.65	1.03	1.65	1.03	2.11	1.3	2.11	1.3	2.5	1.49			2.87	1.71
25	1	33.4	1.65	1.31	1.65	1.31	2.77	2.13	2.77	2.13	3	2.24			3.38	2.54
32	11/4	24.2	1.65	1.67	1.65	1.67	2.77	2.73	2.77	2.73	3	2.9			3.56	3.44
40	11/2	48.3	1.65	1.93	1.65	1.93	2.77	3.16	2.77	3.16	3	3.35			3.68	4.11
50	2	60.3	1.65	1.93	1.65	2.42	2.77	3.99	2.77	3.99	3.5	4.9			3.91	5.52
65	21/2	73	2.11	3.75	2.11	3.75	3.05	5.34	3.05	5.34	3.5	6			5.16	8.77
80	3	88.9	2.11	4.59	2.11	4.59	3.05	6.56	3.05	6.56	4	8.37			5.49	11.47
90	31/2	101.6	2.11	5.25	2.11	5.25	3.05	7.53	3.05	7.53	4	9.62			5.74	13.78
100	4	114.3	2.11	5.93	2.11	5.93	3.05	8.5	3.05	8.5	4.5	12.18			6.02	6.32
125	5	141.3	2.77	9.61	2.77	9.61	3.4	11.74	3.43	11.74	5	16.8			6.55	2210
150	6	168.3	2.77	11.47	2.77	11.47	3.4	14.04	3.43	14.04	5.5	22.08			7.11	28.69
200	8	219.1	2.77	15	2.77	15	3.76	20.77	3.76	20.27	6.35	33.82	7.04	37.38	8.18	43.2			10.81	53.9
250	10	273.1	3.4	22.95	3.4	22.95	4.19	28.2	4.19	28.2	6.35	42.41	7.8	51.81	9.27	61.22			12.2	82.8
300	12	323.9	3.96	31.72	4.19	33.6	4.57	36.54	4.57	36.54	6.35	50.48	8.38	66.2	9.53	75.01	10.31	80.94	14.27	110.62
350	14	355.6	3.96	34.86			4.78	41.99	6.35	55.53	7.92	68.95	9.53	82.58	9.53	82.58	11.13	96	15.06	128.42
400	16	406.4	4.19	42.2			4.78	48.07	6.35	63.61	7.92	79.03	9.53	94.7	9.53	94.7	12.7	125.2	16.66	162.59
450	18	457.2	4.19	47.46			4.78	54.15	6.35	71.69	7.92	89.1	11.13	124.32	9.53	106.83	14.27	158.27	19.05	209
500	2C	508	4.78	60.23			5.54	69.7	6.35	79.76	9.53	118.93	12.7	157.51	9.53	118.9	15.06	185.89	2062	251.65
550	22	558.8	4.78	65.95			5.54	76.75	6.35	87.84	9.53	131.07	12.7	173.66	9.53	131.07	15.88	216.04	22.23	298.55
600	24	609.6	5.54	83.8			6.35	95.92	6.35	95.92	9.53	143.2	14.27	212.72	9.53	143.2	17.45	258.74	24.59	360.21
650	26	660.4							7.92	129.4	12.7	205.97			9.53	155.32
700	28	711.2							7.92	139.47	12.7	222.13	15.88	276.48	9.53	167.44
750	3C	762	6.35	120.15			7.92	149.55	7.92	149.55	12.7	238.28	15.88	296.68	9.53	179.56
800	32	812.8							7.92	159.62	12.7	254.44	15.88	316.88	9.53	191.69	17.48	348.11
850	34	863.6							7.92	169.64	12.7	270.5	15.88	336.96	9.53	203.74	17.48	370.22
900	36	914.4							7.92	179.77	12.7	286.75	15.88	357.28	9.53	215.93	19.05	427.09

ASME SA 312 TP317 Pipes Bodrum, Stainless Steel 317 Pipes Supplier in İzmir, 317 Stainless Steel Pipes Exporter in Ankara, SS UNS S31700 Pipes Supplier in Istanbul, SS 317 Schedule 20 Pipe Exporter in Antalya

Types of Stainless Steel 317 Pipes

Are Custom Sizes Available for Stainless Steel 317 Pipes?

Yes, we offer custom sizes for Stainless Steel 317 Pipes to meet your specific requirements. Our team at Irfan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@irfanpipes.com.

SS UNS S31700 Pipes Exporter in Antalya, SUS 317 Pipes Supplier in Bursa, 317 SS Pipes Manufacturer in Ankara, 317 Austenitic Stainless Steel Pipe Dealer in Istanbul, Stainless Steel S31700 Pipes Manufacturer in Bodrum, SS 317 Pipe Supplier in İzmir

Stainless Steel 317 Pipes find extensive use in industries that demand outstanding corrosion resistance in highly acidic, saline, and chemical environments. They are commonly utilized in chemical processing equipment, pulp and paper mills, textile dyeing machinery, and food and beverage processing systems. Additionally, these pipes are essential in marine engineering, pharmaceutical plants, and power generation, particularly where resistance to sulfuric acid, hydrochloric acid, and chloride stress corrosion cracking is vital. The impressive mechanical properties of SS 317 at high temperatures make it an excellent choice for heat-intensive applications.
