Stainless Steel 17-4 PH Pipes

Home > Stainless Steel >Stainless Steel 17-4 PH Pipes

Stainless Steel 17-4 PH Pipes Manufacturer, Supplier and Exporter in Istanbul, Turkey

Irfan Pipes and Tubes, based in Istanbul, Turkey, has earned a solid reputation as a reliable manufacturer and supplier of Stainless Steel 17-4 PH Pipes, providing top-notch piping solutions to industries around the globe. The company is well-regarded for its precision engineering, dependability, and commitment to international quality standards. Their pipes are designed to deliver exceptional strength, corrosion resistance, and a long lifespan. What sets Irfan’s Stainless Steel 17-4 PH Pipes apart is their remarkable ability to maintain outstanding mechanical properties even under high pressure and stress. Thanks to cutting-edge technology and rigorous quality control, the company guarantees durable and efficient products for critical applications.

17-4 PH Stainless Steel Pipes Exporter in Turkey, SS UNS S17400 Pipes Supplier in Bursa, 17-4 PH Stainless Steel Pipe Manufacturer in Ankara, SUS 17-4 PH Pipes Price List in İzmir, ASTM A312 Stainless Steel 17-4 PH Pipe Distributor in Bodrum, Stainless Steel 1.4542 Pipes in Antalya, Stainless Steel TP17-4 PH Pipe Exporters in Turkey

These Stainless Steel 17-4 PH Pipes are crafted from a precipitation-hardening martensitic stainless steel alloy that includes about 17% chromium and 4% nickel, along with copper and niobium. This unique blend results in high strength, hardness, and impressive corrosion resistance across a range of environments. The pipes can be heat treated to achieve various combinations of strength and toughness, making them adaptable for a wide array of industrial needs. They also boast excellent fatigue strength, wear resistance, and oxidation resistance, while still being easy to weld and machine, even in demanding service conditions.

Stainless Steel 17-4 PH Pipes Specification

Specifications	ASTM A312 / ASME SA312
Dimensional specification	ANSI/ASME B36.19M, ANSI/ASME B36.10M
Size	1 / 8″ NB – 24″ NB
Outside Diameter	6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock
Manufacturing Shapes	Hydraulic, Round, Square, Hex, Honed
Manufacturing Techniques	Normalized & as Rolled
Schedule Thickness Range	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
End Types	Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends)
Surface Finish	No.1, No.4, No.8 Mirror Finish, 2B
Value Added Services	Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing
Inspection and Test Reports	EN 10204 3.1, Mill Test Certificates, Chemical Reports, PMI Test Reports, Mechanical Reports, Third Party Inspection, NABL Approved Lab, Visual Inspection, Destructive Test and Non Destructive Test Reports
Outside Finish	2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Seamless Pipes, Finish as per customer Requirements
Delivery Condition	Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Heat Treatment	Normalized, Normalized & Tempered
Packing of Seamless Pipes	Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials	Sizes and Specifications other than above can be on request

Stainless Steel 17-4 PH Pipes Chemical Composition

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
SS 17-4 PH	0.07	1.0 max	1.0 max	0.03	3.0 – 5.0	Bal	3.0 – 5.0	15.0 – 17.5

SS 17-4 PH Pipes Mechanical Properties

Grade	Tensile Strengtd (ksi) min	Elongation (% in 50mm) min	Yield Strengtd 0.2% Proof (ksi) min	Hardness
17-4 PH	135	16	105	277

Equivalent Grades of Stainless Steel 17-4 PH Pipe

STANDARD	WERKSTOFF NR.	UNS
SS 17-4 PH	1.4542	S17400

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ASME SA 312 TP17-4 PH Pipes Bodrum, Stainless Steel 17-4 PH Pipes Exporters in İzmir, 17-4 PH Stainless Steel Pipe Manufacturers in Ankara, SS UNS S17400 Pipes Supplier in Istanbul, SS 17-4 PH Schedule 20 Pipe Stockist in in Antalya, SS 17-4 PH Pipes Distributor in Turkey, 17-4 PH Stainless Steel Pipes in Bursa

Why Choose Stainless Steel 17-4 PH Pipes from Irfan Pipes and Tubes?

Choosing Stainless Steel 17-4 PH Pipes from Irfan Pipes and Tubes ensures the highest quality products and industry standards. Their pipe offers exceptional corrosion resistance and durability, making it ideal for demanding applications. Irfan offers a wide range of sizes and modifications to meet specific project requirements. Focusing on customer service, they ensure on-time delivery and support throughout the buying process. Their competitive pricing and commitment to quality make them a choice in the market. Additionally, Irfan’s expertise in stainless steel components ensures reliable and durable performance.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Stainless Steel 17-4 PH Pipes Supplier in Istanbul, Turkey

Irfan Pipes and Tubes, one of the largest suppliers of Stainless Steel 17-4 PH Pipes in Istanbul, Turkey, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

Stainless Steel 17-4 PH Pipe Sizes in MM

Nominal Pipe Size		Outside Diameter (mm)	Nominal Wall Thickness Schedule
NPS	DN	OD	SCH5s	SCHl0s	SCH 10	SCH 20	SCH 30	SCH40s	SCH STD	SCH 40	SCH 60	SCH80s	SCH XS	SCH 80	SCH 100	SCH 120	SCH 140	SCH 160	SCH XXS
1/8	6	10.3		1.24				1.73	1.73	1.73		2.41	2.41	2.41
1/4	8	13.7		1.65				2.24	2.24	2.24		3.02	3.02	3.02
3/8	10	17.1		1.65				2.31	2,31	2.31		3.20	3.20	3.20
1/2	15	21.3	1.65	2.11				2.77	2.77	2.77		3.73	3.73	3.73				4.78	7.47
3/4	20	26.7	1.65	2.11				2.87	2.87	2.87		3.91	3.91	3.91				5.56	7.82
1	25	33.4	1.65	2.77				3.38	3.38	3.38		4.55	4.55	4.55				6.35	9.09
1 1/4	32	42.2	1.65	2.77				3.56	3.56	3,56		4.85	4.85	4.85				6.35	9.70
1 1/2	40	48.3	1.65	2.77				3.68	3.68	3.68		5.08	5.08	5.08				7.14	10.15
2	50	60.3	1.65	2.77				3.91	3.91	3.91		5.54	5.54	5.54				8.74	11.07
2 1/2	65	73	2.11	3.05				5.16	5.16	5.16		7.01	7.01	7.01				9.53	14.02
3	80	88.9	2.11	3.05				5.49	5.49	5.49		7.62	7.62	7.62				11.13	15.24
3 1/2	90	101.6	2.11	3.05				5.74	5.74	5.74		8.08	8.08	8.08
4	100	114.3	2.11	3.05				6.02	6.02	6.02		8.56	8.56	8.56		11.13		13.49	17.12
5	125	141.3	2.77	3.40				6.55	6.55	6.55		9.53	9,53	9.53		12.70		15.88	19.05
6	150	168.3	2.77	3.40				7.11	7.11	7.11		10.97	10.97	10.97		14.27		18.26	21.95
8	200	219.1	2.77	3.76		6.35	7.04	8.18	8.18	8.18	10.31	12.70	12.70	12.70	15.09	18.26	20.62	23.01	22.23
10	250	273.1	3.40	4.19		6.35	7.80	9.27	9.27	9.27	12.70	12.70	12.70	15.09	18.26	21.44	25.40	28.58	25.40
12	300	323.9	3.96	4.57		6.35	8.38	9.53	9.53	10.31	14.27	12.70	12.70	17.48	21.44	25.40	28.58	33.32	25.40
14	350	355.6	3.96	4.78	6.35	7.92	9.53		9.53	11.13	15.09		12.70	19.05	23.83	27.79	31.75	35.71
16	400	406.4	4.19	4.78	6.35	7.92	9.53		9.53	12.70	i6.66		12.70	21.44	26.19	30.96	36.53	40.49
18	450	457.2	4.19	4.78	6.35	7.92	11.13		9.53	14.27	19.05		12.70	23.83	29.36	34.93	39,67	45.24
20	500	508	4.78	5.54	6.35	9.53	12.70		9.53	15.09	20.62		12.70	26.19	32.54	38.10	44.45	50.01
22		559	4.78	5.54	6.35	9.53	12.70		9.53		22.23		12.70	28.58	34.93	41.28	47.63	53.98
24	600	610	5.54	6.35	6.35	9.53	14.27		9.53	17.48	24.61		12.70	30.96	38.89	46.02	52.37	59.54
26		660			7.92	12.70			9.53				12.70
28	700	711			7.92	12.70	15.88		9.53				12.70
30		762	6.35	7.92	7.92	12.70	15.88		9.53				12.70
32	800	813			7.92	12.70	15.88		9.53	17.48			12.70
34		884			7.92	12.70	15.88		9.53	17.48			12.70
36	900	914			7.92	12.70	15.88		9.53	19.05			12.70
38		965							9.53				12.70
40	1000	1016						9.53		12.70
42		1067				12.70	15.88		9.53	19.05			12.70
44	1100	1118							9.53				12.70
46		1168							9.53				12.70
48	1200	1219							9.53			12.70
52		1321
56	1422
60	1524

Weight Chart of Stainless Steel 17 – 4 PH Pipes

Nominal Pipe Size		Outside Diameter	Schedule 5 S		Schedule 10 S		Schedule 20 S		Schedule 40 S		Schedule 80 S		Schedule 160 S		XXS
mm	inch	mm	WT mm	WEIGHT (KGM)	WT mm	WEIGHT (KGM)	WT mm	WEIGHT (KGM)	WT mm	WEIGHT (KGM)	WT mm	WEIGHT (KGM)	WT mm	WEIGHT (KGM)	WT mm	WEIGHT (KGM)
3	1/8	10.3	1.2	0.20	1.24	0.28	1.5	0.33	1.73	0.37	2.41	0.47	–	–	–	–
6	1/4	13.7	1.2	0.37	1.65	0.49	2.00	0.58	2.24	0.630	3.02	0.80	–	–	–	–
10	3/8	17.1	1.2	0.47	1.65	0.63	2.00	0.74	2.31	0.840	3.20	1.10	–	–	–	–
15	1/2	21.3	1.65	0.80	2.11	1.00	2.30	1.07	2.77	1.27	3.73	1.62	4.75	1.94	7.47	2.55
20	3/4	26.7	1.65	1.03	2.11	1.28	2.55	1.52	2.87	1.69	3.91	2.20	5.56	2.90	7.82	3.64
25	1	33.4	1.65	1.30	2.77	2.09	2.55	1.94	3.38	2.50	4.55	3.24	6.35	4.24	9.09	5.45
32	1.1/4	42.2	1.65	1.65	2.77	2.70	3.00	2.90	3.56	3.39	4.85	4.47	6.35	5.61	9.70	7.77
40	1.1/2	48.3	1.65	1.91	2.77	3.11	3.00	3.55	3.68	4.05	5.08	5.41	7.14	7.25	11.1	10.18
50	2	60.3	1.65	2.40	2.77	3.93	3.00	4.24	3.91	5.44	5.54	7.48	8.74	11.11	11.07	13.44
65	2.1/2	73.0	2.11	3.69	3.05	5.26	4.00	6.81	5.16	8.63	7.01	11.41	9.53	14.91	14.02	20.39
80	3	88.9	2.11	4.51	3.05	6.45	4.00	8.37	5.49	11.29	7.62	15.27	11.1	21.30	15.24	27.68
100	4	114.3	2.11	5.84	3.05	8.36	4.50	12.18	6.02	16.07	8.56	22.32	13.49	33.54	17.12	41.03
125	5	141.3	2.77	9.47	3.40	11.57	5.00	16.80	6.55	21.8	9.53	30.97	15.88	49.11	19.05	57.43
150	6	168.3	2.77	11.32	3.40	13.84	6.35	25.36	7.11	28.26	10.97	42.56	18.25	67.53	21.95	79.22
200	8	219.1	2.77	14.79	3.76	19.96	6.35	33.31	8.18	42.55	12.7	64.64	23.01	111.27	22.23	107.92
250	10	273.1	3.40	22.63	4.19	27.78	6.35	41.77	9.27	60.31	12.7	96.01	28.58	172.33	25.40	155.15
300	12	323.8	3.96	31.25	4.57	36.00	6.35	49.7	9.53	73.88	12.7	132.05	33.32	238.76	25.40	186.97
350	14	355.6	3.96	34.36	4.78	41.3	7.92	67.80	11.13	94.59

Stainless Steel 17-4 PH Pipe Sizes in MM

SS 17-4 PH Schedule 40 Pipe Price List in Istanbul, Stainless Steel S17400 Pipes Supplier in Bursa, SS 17-4 PH Pipes Price Per Kg, ASTM A312 Stainless Steel 17-4 PH Pipe Exporter in Ankara, AISI 17-4 PH Pipes Stockist in Bodrum, 1 inch SS 17-4 PH Pipe Price List in Antalya, SS 17-4 PH Pipe Weight Chart, SS 17-4 PH Schedule 20 Pipe Thickness, 17-4 PH Austenitic Stainless Steel Pipe Manufacturers in İzmir

Types of Stainless Steel 17-4 PH Pipes

Are Custom Sizes Available for Stainless Steel 17-4 PH Pipes?

Yes, we offer custom sizes for Stainless Steel 17-4 PH Pipes to meet your specific requirements. Our team at Irfan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@irfanpipes.com.

SS UNS S17400 Pipes Exporters in Antalya, ASME SA 312 TP17-4 PH Pipes Bodrum , SUS 17-4 PH Pipes Distributor in Bursa, 17-4 PH SS Pipes Price Per Kg, 17-4 PH Austenitic Stainless Steel Pipe Supplier in Istanbul, SS 17-4 PH Pipe Stockist in İzmir, Stainless Steel 17-4 PH Pipes Dealer in Ankara

You’ll find Stainless Steel 17-4 PH Pipes in industries that demand high strength and corrosion resistance. They’re commonly used in aerospace, marine engineering, petrochemical, and chemical processing sectors, where reliable performance in tough environments is essential. Additionally, these pipes are utilized in power generation, food processing, and paper industries, as well as in the production of shafts, valves, and structural components. Their ability to blend strength, durability, and resistance to corrosive conditions makes Stainless Steel 17-4 PH Pipes a trustworthy choice for critical and long-term industrial applications.
