Home > Incoloy > Incoloy 800/800H/800HT Tubing
Irfan Pipes and Tubes, located in Istanbul, Turkey, has made a name for itself as a top-notch manufacturer and supplier of high-quality Incoloy 800/800H/800HT tubing. With a strong focus on quality and precision, this company caters to a wide array of industrial sectors, providing tubing that adheres to international standards for both performance and reliability. Their products are engineered to endure extreme conditions, boasting impressive corrosion resistance and mechanical stability. By utilizing cutting-edge manufacturing techniques and rigorous quality control processes, Irfan Pipes and Tubes guarantees that every Incoloy 800/800H/800HT tube performs consistently, making them a go-to choice for clients in search of durable, high-performance solutions.
The Incoloy 800/800H/800HT tubing is primarily made up of nickel (30–35%), iron (the balance), and chromium (19–23%), along with trace amounts of titanium, aluminum, and carbon, depending on the specific grade. These alloys are known for their remarkable mechanical properties, such as high tensile strength, excellent creep-rupture resistance, and outstanding stability at elevated temperatures. The 800H and 800HT grades are specially heat-treated to boost their performance at high temperatures, making them resistant to oxidation, carburization, and thermal fatigue. Their unique blend of strength, toughness, and corrosion resistance ensures reliable operation in challenging industrial settings, especially where mechanical stress and chemical exposure are prevalent.
Specifications ASTM B407, B514, B515 / ASME SB407, SB514, SB515
Dimensions ASTM, ASME and API
Size Range 15″NB – 150″NB
Outer Diameter 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Schedule SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Type Seamless / ERW / Welded / Fabricated / LSAW Pipes
Length Single Random, Double Random & Cut Length
Form Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tube
Grade 800 / 800H / 800HT UNS (N08800, N08810, N08811), DIN (1.4876, 1.4958, 1.4959)
| STANDARD | UNS | WNR. | AFNOR | EN | JIS | BS | GOST | OR |
| Incoloy 800 | N08800 | 1.4876 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800 | NA 15 | ЭИ670 | XH32T |
| Incoloy 800H | N08810 | 1.4958 | Z8NC32-21 | X10NiCrAlTi32-20 | NCF 800H | NA 15(H) | ЭИ670 | XH32T |
| Incoloy 800HT | N08811 | 1.4959 | – | X8NiCrAlTi32-21 | NCF 800HT | NA 15(HT) | ЭИ670 | XH32T |
| Element | Alloy 800 | Alloy 800H | Alloy 800HT |
| C | 0.10 max | 0.05 – 0.10 | 0.06 – 0.10 |
| Mn | 1.50 max | 1.50 max | 1.50 max |
| Si | 1.00 max | 1.00 max | 1.00 max |
| S | 0.015 max | 0.015 max | 0.015 max |
| Cu | 0.75 max | 0.75 max | 0.75 max |
| Fe | 39.50 min | 39.50 min | 39.50 min |
| Ni | 30.00 – 35.00 | 30.00 – 35.00 | 30.00 – 35.00 |
| Cr | 19.00 – 23.00 | 19.00 – 23.00 | 19.00 – 23.00 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Incoloy 800/800H/800HT Tubes from Irfan Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Incoloy solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Irfan Pipes and Tubes, one of the largest suppliers of Incoloy 800/800H/800HT Tubing in the Istanbuls, Turkey. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
| Element | Incoloy Alloy 800/800H/800HT |
| Density | 7.94 g/cm3 |
| Melting Point | 1385 °C (2525 °F) |
| Tensile Strength | Psi – 75,000 , MPa – 520 |
| Yield Strength (0.2%Offset) | Psi – 30,000 , MPa – 205 |
| Elongation | 30 % |
Yes, we provide custom sizes for Incoloy 800/800H/800HT Tubes to meet your specific requirements. At Irfan Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@irfanpipes.com.
Incoloy 800/800H/800HT tubing is widely used in chemical and petrochemical plants, heat exchangers, boilers, and furnace components, where resistance to high-temperature oxidation and corrosion is essential. It’s a popular choice in the nuclear and power generation sectors for reactor components, steam generators, and high-temperature piping systems. Moreover, these alloys are well-suited for equipment that handles hydrofluoric and sulfuric acids, as well as other corrosive substances. The tubing also finds applications in oil refining processes, showcasing its versatility and reliability in demanding environments.
