Irfan Pipes and Tubes, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of high-quality Duplex Steel Pipes 2205. These pipes are well-known for their remarkable resistance to corrosion and impressive mechanical strength. With state-of-the-art production facilities and a strong dedication to quality, the company produces both seamless and welded pipes that adhere to strict international standards. Serving industries around the globe, Irfan Pipes and Tubes guarantees precision-engineered products that are built to last and perform reliably. Their Duplex Steel Pipes 2205 are perfect for tough environments, delivering outstanding performance even in aggressive conditions while ensuring consistent quality and timely delivery. This commitment has made the company a trusted partner for industrial piping solutions.
Duplex Steel Pipes 2205 are primarily made up of 22% chromium, 5% nickel, and 3% molybdenum, along with small amounts of manganese, silicon, and nitrogen, which together create a well-balanced austenitic-ferritic microstructure. This unique composition offers excellent resistance to pitting, crevice corrosion, and stress corrosion cracking. On the mechanical side, these pipes boast high tensile strength, with yield strength ranging from 450 to 550 MPa and ultimate tensile strength between 620 and 720 MPa. They also provide good elongation of 25 to 35%, along with impact toughness and hardness that are well-suited for demanding applications. Duplex Steel 2205 maintains its structural integrity even under high pressure and temperature, making it a dependable choice for critical industrial systems.
| Tube Specifications |
|
|---|---|
| Tube Standard | DIN, JIS, ASTM, EN, GB, AISI, ASME Tube Supplier |
| Tube Schedule | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Length | Single Random, Double Random, Standard & Cut length |
| Type | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Tube |
| Tube Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Tube Thickness | 0.3mm – 50 mm |
| Seamless Tube Outer Diameter | 6.00 mm OD up to 250 mm OD, Sizes up to 12” NB |
| EFW Tube size | 5.0 mm – 1219.2 mm |
| Welded Tube size | 5.0 mm – 1219.2 mm |
| wall thickness | 0.020″ –0.220″ (special wall thicknesses available) |
| End | Plain End, Beveled End, Treaded Tube. |
| Specialized in |
|
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Tube Marking | All Tubes are marked as follows: Grade, Standard, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Boiler and Heatexchanger, Oil Tube, Fluid Tube, Gas Tube, |
| Form | Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Tubes, “U” Shape, Pan Cake Coils etc. |
| Material Test Certificates (MTC) |
|
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish,etc |
| Chemical Composition % | ||||
| Cr | Ni | Mo | C | N |
| 22.0-23.0 | 4.50-6.50 | 3.00-3.50 | .030 Max | 0.14-0.20 |
| Mn | Si | P | S | Fe |
| 2.00 Max | 1.00 Max | .030 Max | .020 Max | Balance |
PIPE STANDARD | WERKSTOFF NR. | UNS |
Duplex 2205 Tube | 1.4462 / 1.4462 | S31803 / S32205 |
| Duplex Stainless Steel | 2205 |
| Density | 7.805 |
| Melting Range,℃ | 1450 ℃ |
| Elongation % | 25 min. |
| Tensile Strength (Mpa) | 655 |
| Yield Strngth (Mpa) | 450 |
| Hardness (Brinell) | 293 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Duplex Steel Tubing 2205 from Irfan Pipes and Tubes ensures superior quality and durability, offering outstanding corrosion resistance and high strength. Our dedication to delivering exceptional service and reliable products guarantees customer satisfaction across a wide range of industrial applications. With our expertise in Duplex steel solutions, you can trust us to provide a top-tier, customized piping solution that meets your specific requirements.
Irfan Pipes and Tubes, one of the largest suppliers of Duplex Steel Tubing 2205 in the Istanbuls, Turkey. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Duplex steel products in the region, delivering reliable solutions to meet diverse project requirements.
Yes, we provide custom sizes for Duplex Steel Tubing 2205 to meet your specific requirements. At Irfan Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@irfanpipes.com.
These pipes find extensive use in the chemical, petrochemical, and oil & gas industries, especially for managing corrosive substances like acids, chlorides, and seawater. They are ideal for applications such as heat exchangers, pressure vessels, and process piping in refineries and desalination plants. The food and pharmaceutical industries also take advantage of their sanitary and corrosion-resistant features. Furthermore, these pipes are utilized in marine applications, the pulp and paper industry, and power generation plants, where durability in harsh conditions is essential.
