Home > Carbon Steel > Carbon Steel JISG3461 Pipes
Irfan Pipes and Tubes, located in Istanbul, Turkey, stands out as a top manufacturer and supplier of Carbon Steel JIS G3461 Pipes. They provide high-quality piping solutions specifically designed to handle pressure in high-temperature environments. Thanks to their state-of-the-art production facilities and a strong dedication to international quality standards, the company produces pipes that are not only strong and durable but also boast precise dimensional accuracy. These pipes are well-regarded in various industries, including power generation, boilers, heat exchangers, and chemical processing, where they are relied upon for their dependable performance in challenging high-pressure and high-temperature situations.
The Carbon Steel JIS G3461 Pipes are mainly made from carbon and iron, with carefully controlled amounts of manganese, phosphorus, and sulfur added to improve toughness and machinability. They showcase impressive mechanical properties, such as high tensile and yield strength, exceptional toughness, and the ability to endure thermal stress. Their resistance to deformation at elevated temperatures, along with good weldability and structural integrity, guarantees consistent performance in critical applications that require long-lasting reliability.
| Standards | JIS G3461 Carbon Steel Pipe |
|---|---|
| JIS G3461 Carbon Steel Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| JIS G3461 Carbon Steel Welded Pipe Size | 5.0 mm – 1219.2 mm |
| JIS G3461 Carbon Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| JIS G3461 Carbon Steel Tube Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3461 Carbon Steel Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| JIS G3461 Carbon Steel Seamless Tube Size | 3.35 mm OD To 101.6 mm OD |
| JIS G3461 Carbon Steel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| JIS G3456 Carbon Steel Tube wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| End | Plain End, Beveled End, Treaded Pipe & Tube |
| Marking | All JIS G3461 Carbon Steel Pipe are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Standard | Grade | Chemical Composition Limits (%) | ||||
| C | Si | Mn | P | S | ||
| JIS G3461 | JIS G3461 STB340 | ≤ 0.18 | ≤ 0.3 | 0.30-0.60 | ≤ 0.035 | ≤ 0.035 |
| JIS G3461 STB410 | ≤ 0.32 | ≤ 0.35 | 0.30-0.80 | ≤ 0.035 | ≤ 0.035 | |
| JIS G3461 STB510 | ≤ 0.25 | ≤ 0.35 | 1.00-1.50 | ≤ 0.035 | ≤ 0.035 | |
| rade | Tensile Property (N/mm2) | Yield Point or Yield Strength (N/mm2) | Elongation (%) | ||
| OD ≥20 mm | 10 mm ≤OD ＜20 mm | OD ＜10 mm | |||
| NO. 11 Sample; NO. 12 Sample | NO. 11 Sample | NO. 11 Sample | |||
| Longitudinal | Transverse | Transverse | |||
| JIS G3461 STB340 | ≥ 340 | ≥ 175 | ≥ 35 | ≥ 30 | ≥ 27 |
| JIS G3461 STB410 | ≥ 410 | ≥ 255 | ≥ 25 | ≥ 20 | ≥ 17 |
| JIS G3461 STB510 | ≥ 510 | ≥ 295 | ≥ 25 | ≥ 20 | ≥ 17 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Carbon Steel JISG3461 Pipes from Irfan Pipes and Tubes ensures outstanding corrosion resistance, high strength, and durability. Our Pipe is designed for diverse industrial applications, delivering reliability and performance in challenging environments while maintaining competitive pricing.
Irfan Pipes and Tubes is one of the largest Carbon Steel JISG3461 Pipes suppliers in Istanbul, Turkey, providing a comprehensive range of high-quality pipes tailored for various industries, ensuring reliable delivery and exceptional service to meet diverse project needs.
Yes, we offer custom sizes for Carbon Steel JISG3461 Pipes to meet your specific requirements. Our team at Irfan Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@irfanpipes.com.
These pipes are widely used in boiler systems, superheaters, heat exchangers, and condensers, where transporting fluids under high pressure and temperature is crucial. They also find applications in power plants, petrochemical facilities, and other industrial settings that need efficient and durable piping solutions. With their robust design, cost-effectiveness, and ability to maintain strength in extreme conditions, Carbon Steel JIS G3461 Pipes are the go-to choice for industries that prioritize safe, reliable, and efficient operations in demanding environments.
